AISIN TR60SN VW Audi Lexus Toyota Porsche 09D Transmission Service Overhaul Repair Manual PDF Digital Download

Aisin TR60SN (VW 09D) Transmission Repair Manual | ATSG Service Guide
Digital Download – Instant PDF Access

Master the 6-speed heavy-duty automatic transaxle found in luxury SUVs. This ATSG (Automatic Transmission Service Group) repair manual is the definitive technical resource for the Aisin TR60SN, also known by the Volkswagen designation 09D.

The TR60SN/09D is a sophisticated, electronically controlled 6-speed transmission that uses a unique Lepelletier gear arrangement. Because this unit is gear-ratio sensitive and varies internally based on engine size and torque requirements, having the exact factory-spec data is essential for a successful rebuild or repair.

🔧 Inside This Technical Manual:
- Complete Overhaul Procedures: Detailed step-by-step disassembly and reassembly of the main case and internal components.
- Solenoid Identification & Testing: Full breakdown of the 8-solenoid valve body, including function, failure results, and resistance charts.
- Electronic Diagnostics: Comprehensive wiring schematics, case connector pin-outs (8-way and 14-way), and speed sensor (ISS/OSS) diagnosis.
- Valve Body Mapping: Detailed hydraulic logic, checkball locations, and spring identification.
- Fluid Service Specs: Critical instructions for checking fluid levels via the "stand-pipe" system and correct ATF specifications.
- Clutch & Gear Data: Accurate clearance measurements for B1, B2, and K3 clutch packs, plus thrust washer and bearing identification.

🚗 Vehicle Compatibility
The TR60SN (09D) is the primary 6-speed RWD/4WD transmission for:
Volkswagen Touareg: (2002–2011) All engine sizes (V6, V8, V10 TDI)
Porsche Cayenne: (2003–2010) (S, Turbo, and Base models)
Audi Q7: (2005–2015) 3.0L V6 and 4.2L V8 models
Lexus & Toyota: Used in specific high-torque applications like the Lexus LX570 and Toyota Land Cruiser (check your transmission code).

📂 Product Details
- Format: High-Resolution, Searchable PDF.
- Delivery: Instant Digital Download (no shipping wait!).
- Accessibility: View on any PC, Mac, Smartphone, or Tablet.
- Print-Ready: High-quality formatting—perfect for printing specific diagrams to keep on your workbench.

💡 Why Trust ATSG?
ATSG manuals are written by master technicians specifically for professional transmission shops. They go far beyond generic service manuals by including "Service Updates" that address common factory flaws—such as valve body wear and K2 clutch drum issues—providing the professional "Pro-Tips" needed for a repair that lasts.

Don't risk a costly error on a luxury SUV transmission. Get the professional data and do the job right.

✅ How to Access Your Download
1. Add to cart and complete checkout.
2. After payment, go to Your Account > Purchases and Reviews on Etsy.
3. Find your order and click the Download Files button.
4. Save the PDF to your device for lifetime access.

Please Note: This is a digital product; no physical book will be shipped. Due to the nature of digital downloads, all sales are final. If you have any questions or need assistance, please message me—I’m here to help!
